1. Innovative Through-Type Design

• Horizontal Conveyor System: Ensures stable, scratch-free transportation of lenses (including ultra-thin 0.1mm glass) through the cleaning line, minimizing mechanical contact and damage during processing.
• Continuous Operation: Enables 24/7 production with a throughput of up to 5,000+ pieces/day, ideal for high-volume manufacturing lines.

2. Multi-Stage Ultrasonic Cleaning

• Ultrasonic Cavitation Technology: Employs 40kHz high-frequency ultrasonic transducers to generate micro-bubbles, effectively removing contaminants like dust, oil, fingerprints, and polishing residues from complex surfaces and edge profiles.
• Multi-Zone Processing: Integrates pre-wash, ultrasonic cleaning, DI water rinse, and final pure water spray stages, ensuring thorough cleaning in compliance with Class 10,000 cleanroom standards.
• Stainless Steel Construction: 304/316L stainless steel tanks and pipelines resist corrosion from acidic/alkaline detergents, ensuring long-term durability in harsh cleaning environments.

3. Fully Automated Drying System

• Hot Air Knife & HEPA Filtration: Combines high-pressure hot air (50-80℃ adjustable) with HEPA-filtered clean air to achieve spot-free, streak-free drying within 30 seconds, eliminating watermark risks on high-precision lenses.
• PLC Intelligent Control: Features a touchscreen interface for easy adjustment of parameters (conveyor speed, temperature, cleaning time) and real-time monitoring of process stability.

4. Precision & Versatility

• Customizable Configurations: Adaptable to various lens sizes (from 10mm to 300mm) and thicknesses, with optional modules for anti-static treatment, UV curing, or automatic sorting.
• Low Water & Energy Consumption: Equipped with a recycling system that reduces DI water usage by 30% and energy consumption by 25% compared to traditional cleaning lines.

5. Industry Compliance & Reliability

• Quality Assurance: Meets ISO 9001 and CE standards, with built-in leak detection, overload protection, and automatic fault diagnosis for minimal downtime.
• Applications: Optimized for optical lenses (CCTV, AR/VR), mobile phone cover glass, automotive HUD lenses, and other precision optical components requiring ultra-clean surfaces.
